Classeq P500AWS16 Dishwasher

  • 3 phase 16 amp
  • Integral Water Softener
  • Water Board (WRAS) Compliant

Three wash programs
Intuitive LCD digital display
Simple Two Touch Control Panel Operation
Drain Pump
Rinse booster pump
Continuous Hood Clean System
Colour coded display

£4,055.99 Exc. VAT


Classeq P500AWS16 Dishwasher

The Classeq P500AWS16 dishwasher is a powerful 3 phase (16amps/phase) hood type dishwasher. This WRAS Approved pass-through dish washer with a powerful 9kW boiler element for increased performance. Designed for busy professional kitchens suitable for straight-through or corner situated operation makes it an ideal choice for pubs, restaurants, schools, care homes and hospitals.

Classeq dish washers are manufactured in Staffordshire to a very high standard and with reduced water consumption via a 28 litre wash tank ensures minimised running costs, easy cleaning due to the continuous hood clean and removable front and side panels allows excellent service access.

This impressive UK built machine has a digital control panel clearly displaying running temperatures in both the rinse tank and the wash tank. The user has the option of a 1.5, 3 or 5 minute wash cycle to combat different levels of soiling and with a simple two button, user-friendly switch arrangement, makes operating this appliance extremely easy for staff. Clever software constantly monitors water usage, temperature and number of wash cycles giving valuable information to improve operational efficiencies. Colour coded display for easy wash cycle management.

Featuring an integral rinse pump which boosts the rinse pressure keeping the rinse cycle and rinse temperature constant ensures excellent rinse performance and hygienic sanitation of crockery.

Via the control panel you have the option of switching on temperature interlocks which guarantees specific temperatures are reached during washing, giving absolute peace of mind that your customers are protected from germs & viruses.

In hard water areas a water softener is imperative to ensure good washing results and low dishwasher maintenance. The P500AWS16 has the solution with an integral water softener. Simply top up the salt level when the control panel indicates for you to do so and the machine will do the rest….it’s that easy.

The P500AWS16 is pump drained therefore no need to pull out a drain plug at the end of the day, just switch off and press the button, the machine will automatically drain down. The built-in drain pump also significantly reduces problems at install if your sites waste is too high for a gravity drain appliance.

If you’re looking for a hard working commercial dishwasher then the Classeq P500AWS16 dishwasher is a great option to consider.



Weight 130 kg
Dimensions (HWD) 1460 × 635 × 712 mm
Amps Required

16A 3 Phase

Basket Size

500 mm

Basket Supplied

2 plus cutlery basket



Clear Entry Height

440 mm

Cycle Time

1.5, 3 or 5 minutes


<70 dB

Drain Size



Stainless Steel

Min. supply water pressure

2.0 bar

Operating Voltage


Power Source

Hard wired (3 phase)

Required Water Flow Rate

11 Ltr / min

Rinse Tank Capacity

7.5 Ltr

Rinse Tank Element

8.64 kW

Rinse Water Consumption at 3 bar

3 Litres / Cycle

Total Connected Load

9320 Watts

Water supply connection

G3/4” (3/4” BSP)

Wash Tank Element

4.05 kW

Wash Tank Capacity

28 Litres

Wash Pump Power

0.58 kW


2 years Parts & Labour

Height when hood open

2010 mm
