CP500 Spare Parts Drawings

Welcome to the Classeq CP500 Spare Parts Drawings category within the Classeq Dishwasher Spare Parts section at Barcare. This collection provides detailed exploded parts diagrams and technical drawings specifically for the Classeq CP500 pass-through commercial dishwasher — a heavy-duty machine designed for busy kitchen environments with high-volume warewashing demands. The CP500 delivers reliable and efficient wash performance, with multiple wash programmes, integrated pump systems and simple maintenance features that make servicing easier.

These drawings are essential tools for service engineers, technicians and kitchen maintenance teams to quickly identify the exact part you need, help plan repairs more efficiently, and ensure you order the correct genuine spare. Use these diagrams to support accurate part matching across mechanical, electrical, and functional assemblies in your CP500 dishwasher.
